CAB ROXI
For belt speeds up to 30 m/min
The CAB ROXI series is the ideal solution for the accurate and efficient application of labels in production lines and industrial packaging systems. Developed to deliver high performance whilst taking up minimal space, ROXI combines the reliability of CAB’s ‘Made in Germany’ technology with a streamlined design, making it the perfect choice for direct labelling of products on the production line or via applicators from the HERMES Q series.
ROXI has been engineered to meet the needs of companies, OEMs and system integrators requiring a versatile dispensing head offering excellent value for money. Thanks to its compact design, the unit adapts easily to complex installation scenarios and confined mounting spaces, without compromising label positioning accuracy. This feature makes it particularly suitable for sectors such as industrial packaging, logistics, electronics, the chemical and pharmaceutical industries, and consumer goods, where operational consistency and millimetre-level tolerance are key parameters for process quality.
From an operational perspective, ROXI shares the same software and firmware platform as the higher-end IXOR series, offering a modern user interface, easy firmware updates via network or USB, and seamless integration with line control systems.
Set-up and format changeover times are kept to a minimum thanks to the quick-release web clamp systems and adjustable guide rollers. Native compatibility with a wide range of accessories – including dedicated sensors, dispensing plates and support columns – ensures a secure investment that is scalable over time and ready to meet the requirements of the digital factory.
MANUAL
INFO
Main Features & System Architecture
-
Slim & Compact Design: Optimized compact frame for easy installation into existing conveyor belts and labeling machines.
-
Flexible Assembly: Vertical, horizontal, or inclined installation with left-hand (L) or right-hand (R) label dispensing directions.
-
Protection Class: IP 40 rated construction designed for continuous industrial use.
-
Intuitive Control Panel: Integrated 3.5” color LCD graphics display (QVGA, 54 x 70 mm) with LED keys (ON/OFF, FEED) for straightforward parameter configuration.
-
Shared cab Platform: Shares user interface, basic mounting dimensions, firmware, sensors, dispensing modules, and accessories with the IXOR series.
-
Adjustable Web Brake: Simplifies handling of delicate or die-cut materials; features a quick-release lever for fast roll changes.
Web Speed Performance
The ROXI series is optimized for continuous operations at medium line speeds:
-
Maximum Web Speed: Up to 30 m/min (up to 20 m/min for the ROXI 180 model).
-
Dynamic Speed Control: Support for an external encoder (Masterencoder) to synchronize dispensing speed automatically with the conveyor belt speed.
Interfaces & Industry 4.0 Integration
-
Network Connectivity: Integrated Ethernet interface, USB port, and WLAN support.
-
Smart Factory Protocols: Logical integration via JScript, cab control commands, and support for industrial protocols such as MQTT, OPC UA, and XML event logging.
-
Control Signals: Pre-warning for end of label web, broken liner torque monitoring, and remote diagnostics (including software oscilloscope).
-
Applicator Integration: Seamless combination with HERMES HQ applicators for blow-on/roll-on application on stationary or moving items.
Technical Specifications & Operational Parameters
Working Widths: ROXI 60 (up to 56 mm) / ROXI 120 (up to 116 mm) / ROXI 180 (up to 176 mm)
Liner Width: Up to 60 mm, 120 mm, or 180 mm
Label Length (Feed): From 10 mm to 6,000 mm
Minimum Label Distance: From 2 mm
Label / Liner Thickness: From 0,055 mm to1,0 mm
Label Materials: Paper, synthetic materials (PET, PE, PP, PVC), and booklets (upon request)
Unwinder (Max Roll Outer Diameter): Up to 310 mm; 76 mm (3") core diameter; inside or outside winding; max roll weight 12 kg
Rewinder (Max Roll Outer Diameter): Up to 210 mm; 76 mm core diameter
Label Sensor: Detection of label gaps, label edges, and end of material (CEON or GAB sensors supported)
